SINOCONVE High Quality A Type A15 A16 A17 A18 A19 A20 A21 A28 Transmission Wrapped V-Belt
A-type transmission wrapped V-belts are designed for power transmission in industrial machinery and pulley drive systems. The wrapped construction combines a rubber body, polyester cord reinforcement and an outer polyester-cotton canvas to support stable pulley engagement, controlled elongation and durable operation.
The A15, A16, A17, A18, A19, A20, A21 and A28 length options should be selected according to the existing belt marking, pulley groove, finished length, transmitted load, speed, tension method and working environment. Share the drive information with our team so we can confirm the correct belt specification.
Get a faster, more accurate quote
Click Inquiry Now and include the A-type length mark, belt section, finished length, pulley dimensions, speed, load, quantity and operating conditions.
Listed product configuration
| Product | A-type transmission wrapped V-belt |
| Length options | A15, A16, A17, A18, A19, A20, A21 and A28 |
| Drive type | Pulley-driven friction power transmission |
| Top rubber | NR/SBR as listed in the supplied legacy material |
| Reinforcement | Polyester cord |
| Outer fabric | Polyester-cotton canvas |
| Typical applications | Blending systems, choppers, HVAC systems, lawnmowers, compressors, crushers and scarifiers |
Material and application note
The legacy material describes high load capability, low elongation, fatigue endurance, operational safety, oil/heat/ozone/abrasion resistance, static conductivity to ISO 1813 and a temperature range of -55°C to 70°C. Confirm the applicable compound, test documentation and operating range for the selected belt before treating these statements as product guarantees.
A-type V-belt construction
Multiple section and length options
The A15–A28 product designation can be reviewed with the existing belt marking and drive dimensions to identify the required finished length.
Designed for industrial loads
The legacy material describes high loads, low elongation and fatigue endurance. Confirm the actual load rating and operating conditions for the selected construction.
Layered rubber and cord structure
The supplied structure information lists NR/SBR top rubber, polyester cord reinforcement, NR/SBR buffer rubber, NR/SBR bottom rubber and an outer polyester-cotton canvas.
Applications and related V-belt sections
Typical applications
The supplied legacy material lists blending systems, choppers, HVAC systems, lawnmowers, compressors, crushers and scarifiers.
Related section families
Related legacy tables reference Z/FM/O, 3V, 5V, 8V, SPZ, SPA, SPB, SPC, 3L, 4L, 5L, 8.5×8, RB, RC, RD, RE, R3V, R5V, R8V, RSPZ, RSPB and RSPC. Confirm the required family separately; these are not automatically included in the A15–A28 designation.
Why buyers choose an A-type wrapped V-belt
Supports stable pulley transmission
The molded V-section is intended to seat in a matching pulley groove and transfer power through controlled friction.
Combines cord reinforcement and outer wrapping
Polyester cord reinforcement and polyester-cotton canvas are listed in the supplied construction information. Confirm the final belt construction for the intended machine.
Supports replacement identification
Existing belt marking, length, pulley groove, speed, load and tension method can be reviewed together before replacement.
A-type size reference
| Type | Top width (mm) | Pitch width (mm) | Height (mm) | Length range (mm) | Angle |
| Z/FM/O | 10 | 8.5 | 6 | 280–2480 | 40° |
| A | 13 | 11 | 8 | 330–8000 | 40° |
| B | 17 | 14 | 11 | 457–17000 | 40° |
| C | 22 | 19 | 14 | 700–17000 | 40° |
| D | 32 | 27 | 19 | 1100–17000 | 40° |
| E | 38 | 32 | 23 | 3300–17000 | 40° |
The table reproduces the classical section reference from the supplied legacy material. Confirm the exact length option and matching pulley before ordering.
Application details we check
- Machine type, drive function and required transmission performance.
- Existing belt marking, A-type length option, section and finished length.
- Pulley groove profile, pulley diameter, center distance and alignment.
- Transmitted load, motor power, speed, acceleration and start-stop frequency.
- Ambient conditions involving dust, oil, heat, ozone, chemicals or continuous duty.
- Belt tension method, replacement quantity, packaging and required documentation.
Providing these details helps our team reduce back-and-forth and prepare a more accurate A-type wrapped V-belt recommendation and quotation.
Customization discussion
Depending on the application, ask our sales team about A-type length, rubber construction, polyester cord, outer fabric, belt matching, packaging and inspection documentation. Availability and suitability should be confirmed against the pulley system and required quantity.
Get a technical recommendation and quote
Click Inquiry Now and send your A-type length, belt section, finished length, pulley data, speed, load and operating conditions.
Suggested inquiry: “Please quote an A-type transmission wrapped V-belt, length [A15/A16/A17/A18/A19/A20/A21/A28], finished length [ ], pulley details [ ], speed [ ], load [ ] and quantity [ ].”
Frequently asked questions
What is an A-type wrapped V-belt used for?
It is positioned for pulley-driven power transmission in industrial machinery and equipment where an A-type wrapped V-belt is required.
Which A-type lengths are listed?
The product naming supplied for this page includes A15, A16, A17, A18, A19, A20, A21 and A28. Confirm the exact belt marking and finished length before ordering.
What materials are listed in the belt structure?
The supplied legacy material lists NR/SBR rubber layers, polyester cord reinforcement and an outer polyester-cotton canvas. Confirm the final material construction for the application.
Can the belt be used in different machines?
The legacy material lists blending systems, choppers, HVAC systems, lawnmowers, compressors, crushers and scarifiers. Suitability depends on the pulley, load, speed and working environment.
How do I submit an inquiry?
Use the Inquiry Now link and include the machine type, A-type length, belt marking, pulley data and quantity.
